Module
§
Qualcomm QSC6055
Technology and Frequency
§
CDMA2000 1X, 800MHz/1900MHz
Advanced Technologies
§
Bluetooth 2.0
§
3-axis accelerometer (Bosch BMA150)
§
Standalone GPS, AGPS, gpsOne™
Dimensions and Weight
§
Dimensions: 21×22×4.5mm
§
Weight: 4 grams
Interfaces
90-pin
board-to-board connector including:
§
USB 2.0 Full Speed
§
Bluetooth 2.0
§
I2C
§
RUIM support
§
LCD (parallel)
§
Camera (1.23Mpixel)
§
Keypad (5×5 matrix)
§
Keypad backlight drive
§
2 LED control lines
§
Vibrator control
§
General Purpose PDM (LCD backlight and
brightness control)
§
Audio –handset, headset, speaker
§
Primary antenna RF coax
Low
Power
§
Enables use of low duty cycle
Power
requirements
§
Operating Vcc: 3.2 - 4.2 V
§
USB charging (Li-ION):
5V ±10%,
500mA
§
Output interface voltages (1.8V, 2.6V, 2.85V)
APIs and SDKs
§
BREW MP
§
AT command interface
§
Documentation
STANDARDS/ CERTIFICATIONS
§ FCC type acceptance
§ R&TTE Directive
1999/5/EC
§ RoHS Directive
2002/95/EC
ENVIRONMENTAL
§ Operating
temperature:
-30℃
to +70℃
§ Storage temperature:
-55℃ to +100℃
