| 产品名称：EVDO Card PD(EV5) |
 |
| 产品编号：235021-416 |
| 产品型号：EV5 |
| 市场价格：0元/个 批发价格：0元/个 |
| 更新时间：2009.09.04 |
| 出品单位：信源通科技(深圳)有限公司 |
| 浏览次数： |
|
 产品详细介绍 |
|
Key Drivers
The key drivers are defined from the benchmark study and constrain from the
technology roadmap.
|
Key Drivers |
|
Platform |
QUALCOMM 6085 |
|
RF band |
Cellular850MHZ, PCS1900MHZ |
|
Chipset |
QSC6085, |
|
Size |
72.8 x 35.2 x 8.7 mm
|
|
Data function |
Yes |
|
SMS function |
Yes |
|
Voice function |
No |
|
PC Voice function |
NO |
|
Auto running |
Yes 支持一键安装（即插即用，无需手动安装驱动） |
|
System Flash Memory |
512M+256M |
|
MP3 Play via Speaker |
No |
|
USB |
USB |
|
T-flash |
YES |
|
Built-in Data Flash Memory |
No |
|
Battery |
None |
|
Standby current |
TBD |
|
SIM voltage |
2.85V/1.8V |
|
Indicator |
Yes |
|
Headset jack |
No |
|
FM Radio |
No |
|
MP3 Player |
No |
|
Bluetooth |
No |
|
Alert Speaker |
No |
|
网络在线，同时能够收发短消息 |
Yes |
|
网络在线，拨打电话 |
Yes |
|
用户内存 |
|
|
AT Command control |
Yes |
|
Support PC OS |
Windows®2000,Windows®XP,Windows®Vista |
|
支持MAC OS |
Yes(在苹果机上实现拨号上网) |
|
支持64位操作系统 |
Windows®2000,Windows®XP,Windows®Vista |
|
Data rate |
Max 3.1Mbps（理论值） |
|
Supply Voltage |
5V(on PC) |
|
Current Consumption
Max.(Peak) |
600mA |
|
Interface Type |
USB |
|
Antenna Type |
external |
|
Incept sensitivity |
<-102dBm |
|
Work temperature |
-20℃ - +60℃ |
|
Storage temprature |
-30℃ - +80℃ |
|
Temp/Humidity test |
40℃/75℅ |
|
Size |
72.8 x 35.2 x 8.7 mm |
|
Weight |
<50g |
|
Cover shell material |
sheet metal + plastic |
|
分模工艺缝 |
Yes |
|
Indicator |
Yes(three-color led) |
|
connector type |
USB |
|
Earphone socket |
NO |
|
Antenna socket |
No |
|
RF test socket |
Yes |
|
SIM card socket |
Yes |
|
Call |
Speech call |
NO |
|
Emergency call |
NO |
|
DTMF |
NO |
|
CDMA Data call |
Yes |
|
EVDO Data call |
Yes |
|
Outgoing call records |
NO |
|
Answered call records |
NO |
|
Missed call records |
NO |
|
Call records |
NO |
|
Phonebook |
Storage No. |
SIM Card,PC |
|
Fast search |
Support Chinese, English |
|
Copy |
SIM card to PC ,PC to SIM Card |
|
Select storage location |
SIM card or PC |
|
Own No. |
Support |
|
SMS |
SMS Number |
500(PC) |
|
Long message(SMS concatenation) |
Support Text |
|
SMS (Class) |
class 0.1.2 |
|
SMS format |
PDU |
|
Storage location selection |
PC |
|
Network Function |
Call forward |
NO |
|
Call limit |
NO |
|
Call waiting |
NO |
|
Network selection |
Auto-select, manual-select,Auto/manual-select |
|
Preferred network |
Yes |
|
Listed network |
Yes |
|
Accessory |
Earphone |
No |
|
PC driver |
Yes(内置) |
|
Charger |
No |
|
USB Cable |
Option |
|
指示灯定义 |
序号 |
功能定义 |
功能描述 |
|
LED01 |
|
红光闪烁---无信号 |
|
红色—POWEROFF |
|
兰色慢闪-----3G网络 |
|
兰色快闪-----3G网络数据传输中 |
|
绿色慢闪-----2G网络 |
|
绿色慢闪-----2G网络数据传输中 |
特别说明：指示灯可参考电信规范进行修改 |
| |
|
